Category Crossflow infill
Cooltech Alliance PTE LTD provides high performance compatible fill replacement for any square package or large industry type crossflow cooling tower. Our vacuum formed polyvinyl chloride (PVC) film type media is an excellent, cost effective selection for your crossflow cooling tower. All our material meets CTI 136 specifications and tested by third party. Standard thickness for this fill is 0.30mm. Other thickness are also available upon request. This fill sheets are easily bonded into packs and is bottom supported.
| Technical Specification | |
|---|---|
| Material | PVC |
| Colour | Black |
| Fill Height (H) | 1000mm |
| Fill Width (AT) | 1000mm |
| Standard Thickness (before form) | 0.3mm |
| Sheet Pitch | 16 mm |
| Maximum Suspended Solids | 25ppm |
| Support Method | Bottom |
| Max Water Temperature | 52 °C |
